- 8 -
Before Use
Names and Functions of Main Parts
1 Flash (P59)
2 Self-timer indicator (P64)
AF Assist Lamp (P99)
3 Lens (P6, 182)
4 Speaker
•
Be careful not to cover the speaker with your
finger. Doing so may make sound difficult to
hear.
5 Lens barrier
6 Monitor (P56, 163, 182)
•
Peel off the protective film before use.
7 [EXPOSURE] button (P67, 68, 69)
8Charging lamp (P13)
Wi-Fi
®
connection lamp (P123)
9 Motion picture button (P34)
10 [(] (Playback) button (P37)
11 [MENU/SET] button (P41)
12 [Q.MENU] button (P43)
[ ] (Delete/Cancel) button (P40)
13 [DISP.] button (P56)
14 Cursor buttons
A: 3/[
È] (Exposure compensation/Auto
Bracket) (P65, 66)
B: 4/[
#] (Macro Mode/AF Tracking) (P63, 96)
C: 2/[
ë] (Self-timer) (P64)
D: 1/[
‰] (Flash setting) (P59)
In this owner’s manual, the cursor buttons are described as shown in the figure below
or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
6 87 910
121314
11
