Panasonic LUMIX DMC-ZS60 Operating Instructions For Advanced Features

55
SQW0566
Basics
Buttons/Dials/Levers Used for Recording
Enabling/disabling the histogram display
→ [Custom] → [Histogram] → [ON] / [OFF]
When set to [ON], you can move the display position of the histogram by pressing .
• Direct touch operation is also possible from the recording screen.
Displays distribution of brightness in picture – e.g.
if the graph peaks at the right, this means there are
several bright areas in the picture. A peak in the centre
represents correct brightness (correct exposure). This
can be used as a reference for exposure correction, etc.
(Example)
Dark ← OK → Bright
●
When the histogram is not the same as that of the recorded picture under the following
conditions, histogram will be displayed in orange:
• When manual exposure assist indicates settings other than [
] in Manual Exposure Mode
or during Exposure Compensation.
• When the flash fires.
• When the correct exposure is not achieved or when the brightness of the screen cannot be
displayed accurately in a dark location.
●
The histogram is different from those displayed using the image editing software of a computer.
Enabling/disabling the guideline display
→ [Custom] → [Guide Line] → [ ] / [ ] / [ ] / [OFF]
• The guideline is not displayed during panorama picture recording.
When you select [ ] , you can move the position of the guideline by pressing .
• You can also set the position directly by touching [ ] on the guideline of the recording
screen.

Panasonic LUMIX DMC-ZS60 Specifications

General

Sensor	MOS
Sensor Size	1/2.3 inch
Lens	LEICA DC VARIO-ELMAR
Digital Zoom	4x
Focal Length	4.3 - 129mm (35mm Equivalent: 24-720mm)
Maximum Aperture	f/3.3 - 6.4
Touch Screen	No
Built-in Flash	Yes
Shutter Speed	4 - 1/2000 sec
Continuous Shooting	10 fps
Video Recording	4K UHD (3840 x 2160) at 30p, Full HD (1920 x 1080) at 60p
Display	3.0-inch LCD
LCD Screen Resolution	1040k dots
Viewfinder	Electronic Viewfinder (EVF)
Viewfinder Resolution	1, 166k dots
Image Stabilization	5-Axis Hybrid O.I.S.
Connectivity	Wi-Fi
Battery	Rechargeable Lithium-Ion Battery Pack, 3.6V, 1025mAh
Battery Life	320 shots (CIPA standard)
Memory Card Slot	SD/SDHC/SDXC
Weight	282 g (including battery and SD card)
ISO Sensitivity	80-3200 (Extended Mode: 6400)
Dimensions	112 x 64 x 38 mm
