Panasonic LUMIX DMC-ZS60 Operating Instructions For Advanced Features

56
SQW0566
Basics
Buttons/Dials/Levers Used for Recording
Using the level gauge
If you want to make sure that the camera is not slanted or tilted, for example, when you
take a picture of a landscape, use the level gauge indication as a reference.
1
Press [DISP.] button to display the level gauge
The yellow line indicates the current angle. Correct the angle of the camera so that it
matches the white line.
Tilting up or down
• In this case, it is facing upward.
Tilting left or right
• In this case, the right side has
dropped.
• When the camera is tilted very little or not at all, the level gauge will turn green.
●
Even when angle is more or less corrected, there may be an error of about ±1 degree.
●
When [Level Gauge] is assigned to a function button, you can turn the level gauge on and off
every time you press the function button.
●
The level gauge may not be displayed correctly or the direction detect function (→44) may not
operate correctly if the pictures are taken with the camera pointing sharply up or down.

Panasonic LUMIX DMC-ZS60 Specifications

General

Sensor	MOS
Sensor Size	1/2.3 inch
Lens	LEICA DC VARIO-ELMAR
Digital Zoom	4x
Focal Length	4.3 - 129mm (35mm Equivalent: 24-720mm)
Maximum Aperture	f/3.3 - 6.4
Touch Screen	No
Built-in Flash	Yes
Shutter Speed	4 - 1/2000 sec
Continuous Shooting	10 fps
Video Recording	4K UHD (3840 x 2160) at 30p, Full HD (1920 x 1080) at 60p
Display	3.0-inch LCD
LCD Screen Resolution	1040k dots
Viewfinder	Electronic Viewfinder (EVF)
Viewfinder Resolution	1, 166k dots
Image Stabilization	5-Axis Hybrid O.I.S.
Connectivity	Wi-Fi
Battery	Rechargeable Lithium-Ion Battery Pack, 3.6V, 1025mAh
Battery Life	320 shots (CIPA standard)
Memory Card Slot	SD/SDHC/SDXC
Weight	282 g (including battery and SD card)
ISO Sensitivity	80-3200 (Extended Mode: 6400)
Dimensions	112 x 64 x 38 mm
