12 Camera ON/OFF switch (P18)
13 Zoom lever (P46)
14 Speaker (P120)
15 Microphone (P82, 106, 135)
16 Shutter button (P38, 82)
17 Mode dial (P36)
18 Hand strap eyelet
•
Be sure to attach the hand strap when
using the camera to ensure that you will
not drop it.
19 Lens barrel
20 [COMPONENT OUT] socket (P148)
21 [AV OUT/DIGITAL] socket (P138, 141,
147)
22 Tripod receptacle
•
When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
23 Card/Battery door (P14)
24 Release lever (P14)
25 DC coupler cover (P15)
•
When using an AC adaptor, ensure that
the Panasonic DC coupler (optional) and
AC adaptor (optional) are used. For
connection details, refer to P15.
