Panasonic LUMIX GH5 II Owner's Manual

30
DVQX2185 (ENG)
Getting Started / Basic Operations
Attaching a Lens

Lenses That Can Be Used
This unit can use the dedicated lenses
compatible with the Micro Four Thirds™
System lens mount specification (Micro Four
Thirds mount).
You can also use the Leica M Mount
interchangeable lens by attaching the M
Mount Adaptor (DMW-MA2M: optional).
• Refer to catalogs/websites for most current information
regarding supported lenses.
https://panasonic.jp/support/global/cs/dsc/
(English only)
A
A
Lens fitting marks

Removing a Lens
• While pressing the lens release button
B
, rotate
the lens in the direction of the arrow until it stops
and then remove it.
B
• After removing the lens, be sure to attach the body cap and the lens rear cap.

Panasonic LUMIX GH5 II Specifications

General

Sensor Type	Live MOS
Megapixels	20.3 MP
Sensor Size	17.3 x 13.0 mm
Image Sensor Format	Four Thirds
Image Processor	Venus Engine
Viewfinder	OLED Live View Finder
Dimensions	138.5 x 98.1 x 87.4 mm
Autofocus System	Contrast Detection
Video Resolution	4K (3840 x 2160)
Viewfinder Resolution	3, 680k-dot
Screen	3.0" Free-Angle Touchscreen LCD
Screen Resolution	1, 840, 000 Dot
Image Stabilization	5-axis in-body image stabilization
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	12 fps
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 Shots
Battery	DMW-BLK22 Lithium-ion
Weight	727 g
