Materials
Interchangeable Lens H-ES12060
“LEICA DG VARIO-ELMARIT 12–60mm/F2.8–4.0
ASPH./POWER O.I.S.”
Mount Micro Four Thirds Mount
Focal length f=12 mm to 60 mm
(35 mm film camera equivalent: 24 mm to 120 mm)
Lens construction 14 elements in 12 groups
(4 aspherical lenses, 2 ED lenses)
Aperture type 9 diaphragm blades/circular aperture diaphragm
Maximum aperture F2.8 (Wide) to F4.0 (Tele)
Minimum aperture
value
F22
Angle of view 84° (Wide) to 20° (Tele)
In focus distance Wide: 0.20 m (0.66 feet) to
/
Tele: 0.24 m (0.79 feet) to
(from the focus distance reference line)
Maximum image
magnification
0.3x (35 mm film camera equivalent: 0.6x)
Optical image
stabilizer
Yes
Filter diameter 62 mm
Maximum diameter Ø68.4 mm (2.7″)
Overall length Approx. 86 mm (3.4″)
(from the tip of the lens to the base side of the lens mount)
Mass (Weight) Approx. 320 g / 0.70 lb
Dust and splash
resistant
Yes
Recommended
operating temperature
-10 °C to 40 °C (14 °F to 104 °F)
Permissible relative
humidity
10 %RH to 80 %RH
• LEICA is a registered trademark of Leica Microsystems IR GmbH. ELMARIT
is a registered trademark of Leica Camera AG. The LEICA DG lenses are
manufactured using measurement instruments and quality assurance systems
that have been certified by Leica Camera AG based on the company’s quality
standards.

Panasonic LUMIX GH5 II Specifications

General

Sensor Type	Live MOS
Megapixels	20.3 MP
Sensor Size	17.3 x 13.0 mm
Image Sensor Format	Four Thirds
Image Processor	Venus Engine
Viewfinder	OLED Live View Finder
Dimensions	138.5 x 98.1 x 87.4 mm
Autofocus System	Contrast Detection
Video Resolution	4K (3840 x 2160)
Viewfinder Resolution	3, 680k-dot
Screen	3.0" Free-Angle Touchscreen LCD
Screen Resolution	1, 840, 000 Dot
Image Stabilization	5-axis in-body image stabilization
Shutter Speed	1/8000 to 60 sec
Continuous Shooting	12 fps
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 Shots
Battery	DMW-BLK22 Lithium-ion
Weight	727 g
