Specifications
The specifications are subject to change for performance enhancement.
INTERCHANGEABLE LENS FOR DIGITAL CAMERA “LUMIX S PRO 50 mm F1.4”
Mount Leica Camera AG L-Mount
Focal length f=50 mm
Lens construction 13 elements in 11 groups (2 aspherical lenses, 3 ED lenses)
Aperture type 11 diaphragm blades/Circular aperture diaphragm
Maximum aperture F1.4
Minimum aperture value F16
Angle of view 47o
Recording range 0.44 m (1.44 feet) to ¶ (from the focus distance reference line)
Maximum image
magnification
0.15k
Image stabilizer No
Filter diameter 77 mm
Maximum diameter ‰90 mm (3.5q)
Overall length
Approx. 130 mm (5.1
q
) (from the tip of the lens to the base side of the lens mount)
Mass (Weight) Approx. 955 g (2.105 lb)
Dust and splash resistant Yes
Recommended operating
temperature
j10 oC to 40 oC (14 oF to 104 oF)
Permissible relative
humidity
10%RH to 80%RH
