Panasonic MINAS-BL GP series User Manual

－
5
－－
4
－
CAUTION
Do not subject the brushless amplier, motor
or shaft to high impact.
The failure could result in malfunction.
If trip occurs, remove the causes of the trip and
secure the safety before restarting.
The failure could result in injuries.
Execute the trial-operations with the motor xed
and a load unconnected. Connect a load to the
motor after the successful trial-operations.
The failure could result in injuries.
Use the specied voltage on the product.
The failure could result
in electric shocks, injuries, or re.
Install a safety device against idling or locking
of gear head, and leakage of grease.
The failure could result in injuries,
damages, and contaminations.
Do not modify, dismantle or repair the product.
The failure could result
in electric shocks, injuries, or re.
Do not block the heat dissipation hole.
The failure could result
in electric shocks, or re.
Maintenance and check must be performed by
an expert.
The failure could result
in injuries and electric shock.
Conduct proper installation according to
product weight or rated output.
The failure could result
in injuries, or damages.
Use the motor and amplier with the specied
combination.
The failure could result in re.
Ambient temperature of installed motor and
amplier should be under permittable one.
The failure could result in damages.
This product should be treated as an industrial
waste when it is disposed.
Be sure to turn off power when not using it for
a prolonged time.
The failure could result in injuries due
to unintentional operation.
Introduction/ Checking the model
After unpacking
• Make sure that the model is what you have ordered.
• Check whether the product has been damaged or not during transportation.
If any deciency should be found,
contact the dealer store where you bought this product.
Checking the model of Amplier, Motor and Gear head
This amplier is designed for use in combination with a motor to be specied by us.
Check a name of series, rated output, voltage specications you wish to use
You must not use any other combinations than those listed below:
Standard
Shaft
type
Voltage Out put
Amplier
Type
Applicable
Motor
Applicable Gear head
GV series
Pinion shaft
Single phase
AC100 to 120 V
50 W MBEG5A1BCV MBMU5AZAX
MX8G
□
B *
Reduction ratio: 3 to 180
90 W MBEG9A1BCV MBMU9A1AZ
MZ9G
□
B *
MY9G
□
B *
Reduction ratio: 3 to 200
130 W MBEG1E1BCV MBMU1E1AZ
Single phase/
3-phase
AC200 to 240 V
50 W MBEG5A5BCV MBMU5AZAX
MX8G
□
B *
Reduction ratio: 3 to 180
90 W MBEG9A5BCV MBMU9A2AZ
MZ9G
□
B *
MY9G
□
B *
Reduction ratio: 3 to 200
130 W MBEG1E5BCV MBMU1E2AZ
Round shaft
Single phase
AC100 to 120 V
50 W MBEG5A1BCV MBMU5AZAS
—
90 W MBEG9A1BCV MBMU9A1AS
130 W MBEG1E1BCV MBMU1E1AS
Single phase/
3-phase
AC200 to 240 V
50 W MBEG5A5BCV MBMU5AZAS
90 W MBEG9A5BCV MBMU9A2AS
130 W MBEG1E5BCV MBMU1E2AS
GP series
Pinion shaft
Single phase
AC100 to 120 V
50 W MBEG5A1BCP MBMU5AZAB
MB8G
□
BV *
Reduction ratio: 5 to 50
90 W MBEG9A1BCP MBMU9A1AB
MB9G
□
BV *
Reduction ratio: 5 to 50
130 W MBEG1E1BCP MBMU1E1AB
Single phase/
3-phase
AC200 to 240 V
50 W MBEG5A5BCP MBMU5AZAB
MB8G
□
BV *
Reduction ratio: 5 to 50
90 W MBEG9A5BCP MBMU9A2AB
MB9G
□
BV *
Reduction ratio: 5 to 50
130 W MBEG1E5BCP MBMU1E2AB
* A gure representing reduction ration in
□
e.g.) Part number of MX type gear head with reduction ratio 10 is MX8G10B.
Safety Precautions
Important
Do not frequently turn on and off the master
power source.
The failure could result in malfunction.
Do not place any obstacle that blocks ventilation
around the brushless amplier and the motor.
The failure could result in burns or re.
