Water supply hose
Connecting the water supply hose
CAUTION
z Tighten the nut firmly.
z Do not twist, squash, modify or cut
the hose.
1
Water inlet
2
Min.
10 mm
3/4"
1
2
3
Drain hose
Draining to a sink or wash basin
NOTICE
Elbow
(supplied)
Draining to a stand pipe
Stand pipe
Draining to a drain hole
NOTE
47
