- 10 -
NC-TWS30
2.11. Lid, Pump comp.
1. Remove 4 screws off.
2. Use minus screwdriver to pry between Lid and
Pump comp.
Fig. 12
Tapping screw.
M (4 x 12)
Pump comp.
Lid
2.12. Valve A, Spring B, Seal ring
1. Remove Valve A from Pump comp..
2. Remove Spring B off.
3. Remove Seal ring A from Valve A.
Fig. 13
Valve A
Seal ring
Spring B
Leg
Leg
Push
