- 11 -
NC-TWS30
Fig. 14
2.13. Shaft
Push lower part of Pump comp. and push 4 legs of Shaft then pull out.
Shaft
Push
Leg Leg
Shaft
Push
PushPush
2.14. Lock knob A, Lock spring A,
Lock spring B
1. Catch Lock spring A by wrench and pull out.
2. Follow the first section and remove Lock spring B.
3. Remove Lock knob B off.
Fig. 15
Lock spring A
Lock spring B
Lock spring B
