Panasonic NC-TWS30

- 13 -
NC-TWS30
2.17. Lock lever A (Assemble -
Remove Knob)
Bottom up Thermo Pot and press Lock lever A deepest
then push it down and pull out.
Fig. 18
Lock lever A
w Remove this portion
as shown with arrow
2.18. Upper Frame
1. Remove all the components attached to the cover
plate, and remove the cover plate.
2. Remove the case A comp..
3. Remove the control unit B (operation).
4. Remove the upper frame from the container comp..
Fig. 19
Upper frame
