3.6 cm
5 cm
3 cm
Installation
Ensure that the below air gaps are followed
The clearance between the top of the refrigerator and the ●
ceiling is at least 3.6 cm.
The clearance between the wall and the rear of the refrigerator ●
is at least 5 cm.
The clearance from the side of the refrigerator and the wall is ●
at least 3 cm.
Do not ● locate the refrigerator in a humid place as rust may
form and may cause electrical leakage.
Do not ● locate the refrigerator in an area that exposes it to
direct sunlight.
Do not ● locate the refrigerator near any heat generating source
such as a cook top, dishwasher or oven.
The refrigerator must be located in a place that ensures there ●
is good air circulation around the refrigerator.
If the refrigerator is placed on an uneven surface, use the ●
adjustable feet to ensure the refrigerator stands level.
When moving or shifting the refrigerator, remove the ice twister, top freezer case, water evaporator ●
pan etc. and check to be sure there is no water in the refrigerator.
When the refrigerator has been moved to the location, turn the adjustable front feet to ensure that ●
the refrigerator is stable.
If the unit cannot be transported upright, please contact the customer care center for further ●
guidance. Transporting the unit on the incorrect side may cause damage to the refrigerator.
The refrigerator LED lamp is designed specifi cally for this product. If replacement is required, ●
please contact your dealer or authorised service agent.
This appliance must be properly grounded. ●
To extract the power cord from the unit for use, remove the water evaporator pan, extract the ●
power cord and reinsert the water evaporator pan.
Ventilation Requirements
Area Around the Installed Unit
Moving or shifting
LED lamp and Grounding
Power Cord
5
