Panasonic NV-RX24 - Page 18

L
H
100µ
L6801
CABLE
FLAT CARD
DIAL
FOCUS
VWJ0121
W6801
:AUDIO MAIN SIGNAL PATH IN REC MODE
ORDER A PART. PLEASE REFER TO PARTS LIST.
SCHEMATIC DIAGRAM FOR ORDERING. WHEN YOU
NOTE:DO NOT USE ANY PART NUMBER SHOWN ON THIS
(NV-RX27EN ONLY)
VRV0294
VR6801
1
3
5
2
4
JB
JA
MICROPHONE
VCC
ROUT
D6802 PH310
D6801 BR2202S-20B1
6.3V220
C6801
MA165VT
D6806
MA165VT
D6805
RPM6937-V4
IC6801
3
2
1
Page:36
TO LUMI.CHRO./
FP6801
FP4002-1
FP4002-2
FP4002-3
FP4002-4
FP4002-5
FP4002-6
FP4002-7
FP4002-8
FP4002-9
FP4002-10
FP4002-11
FP4002-12 ECM OUT
ECM GND
SYS REG 5V
SYS GND
TALLY LED
REMOTE CTL
IR OUT
V REF
MF VR2
MF VR1
V REF
12
11
10
9
8
7
6
5
4
3
2
1
C
B
A
54321
SENSOR
WHITE BALANCE
TALLY LAMP
(IR RECEIVER)
