4.1.7.1.3 Method -3:
TOP PREVIOUS NEXT
1. Perform Step 3 through Step 8 of Method -1.
Note:
After repairing mechanical trouble, make sure that all gear alignments are correct, especially the
Wiper Arm Unit and Drive Rack Unit of Cassette Up Ass´y. (Refer to " EJECT Position Confirmation
" inDisassembly/Assembly Procedures of Mechanism.)
