Panasonic PV DF2004 - Connecting the “1, 2” AV Input Terminals; Using AV Input Terminal 1

15
Getting Started
Connects VCRs and other peripheral equipment
 AV Input terminal 1 is used
Connecting the “1, 2” AV Input Terminals
• Similar connections are available at the “1, 2” AV input terminals.
• AV Input terminal 2 is located on the front of the unit.
Notes
Audio
OUT
Video
OUT
RL
