Input
Pan pot position
Output
Effect
Center Sub A and Sub 8
Return
1
Counterclock-
Sub A
w ise
Clockwise Sub B
Effect Center
Sub A and Sub 8
Return 2
Counter clock - Sub A
wise
Clockwise
Sub B
(10 1 Sum Peak Indicator LEOs
These LEDs light at + 14 dB, whi ch is 6 dB down from
the summing point pre - fader clipping l evel (+ 20 dB)_
When this LI ED lights , output signals will be distorted .
In this case, lower all input faders so {hat LED does
not light .
(11) Sub A/Sub B Output Faders
60 mm carbon faders, used to adjust Sub A Elnd Sub
B output levels . Posit i on 0 represents the rated out-
put level.
(12) Meter Selector Switch
This switch selects either the Main or Effect signal to
be displayed on its respective bar - graph meter .
When any solo switch IS on, the meter displays solo
level regardless of the SWitch pOSition.
(13) Effect Output Control
Master level control for Effect output .
(14) Record Output Control
Record output level adjusting knob . Channel A and
Channel 8 are simultaneously adjusted .
Sub A and Sub B pre-fader level signals feed this
control.
(15) Main Output Pre/Post Selector Switch
This switch sets the Main output to the pre-fader level
or post-fader level of Sub A and Sub B.
Pressing the switch down sets Main output to pre-
fader level, and pressing It again to the up position
returns Main output to post-fader level.
Pre: Ma in output signal IS derived pre- Sub
A/Sub B faders . This mode allows
separate stereo and mono mixes
si multaneously.
Post : Main output signal is deri ved post-
Sub A/Sub B faders. This is useful for
sub group i ng of inputs .
Note:
In "Post" pos i tion Sub A and Sub B faders mu st be
raised for
output signal to be present at Main output .
- 8 -
(16) Main Output Fader
A 60 mm carbon fader for adjusting Main output level.
Position 0 represents the rated output level. The Ma in
output signal is a summed monaural signal from Sub
A and Sub B
(17) Power Switch
When this switch is pressed, mixer power IS turned
on and the power indicator LED lights.
A muting circuit is prov i ded for protecting the devices
connected to the output from click noise. The unit is
ready for operation about 5 or 6 seconds after swit-
ching power on .
(18) Phantom Power Switch
This power switch is for condenser microphones, and
turns 0 C 48 V on and off.
Be sure to use a balanced type condenser microphone
because DC I 48 V is applied to pin 2 (hot) and pin
3 (cold) of the microphone connector and DC 0 V to
pin 1 (Common) .
Turn all output faders to the minimum position to pre-
vent click noise before turning the phantom power
switch on or off.
Note:
The power sw it ch (17) and phantom power sw i tch
(18) on the WR-S 208 are located on the operat i on
panel because the WR-S208 may be mounted in a
rack.
When connect ing a microphone to the microphone
connector , make sure that phantom power is off .
(19) Headphone Selector Switch
This switch is used for select ing signals to be
monitored with the headphones .
When this switch is pushed down, Main output can
be monitored monaurally . When the switch is push-
ed again to the up posit i on, Sub A and Sub B outputs
ca n be monitored in stereo.
(20) Phones Control
Th is knob is used for adjusting headphone monitor
level. Sub A and Sub B signals are simultaneously
adjusted.
(21) Solo Control
This control adjusts the level of the solo signal pre-
sent at the headphone output.
(22) Solo Indicator LED
This LED tights if anyone of the input solo switches
is on.
(23) Phones
1/4" TRS phone jack for headphones .
Maximum output is 1.2 W + 1.2 W/8 ohms.
