OPERATION
Names of Parts
INDOOR UNIT
Wireless Remote Controller (Optional parts)
Timer Remote Controller (Optional parts)
Refer to the Operating Instructions attached to the
optional Wireless Remote Controller.
Refer to the Operating Instructions attached to the
optional Timer Remote Controller.
Water drain
Ceiling panel
(optional)
Air outlet
(4 locations)
Air intake grille
(air intake)
Suspension
bolt
Ceiling material
Bolt anchor
Air outlet duct
Indoor unit
Air-outlet grille
U1 Type (4-WAY CASSETTE) F2 Type (LOW SILHOUETTE DUCTED)
NOTE
(Wireless type: available
for all indoor units)
NOTE
(Wired type: available
for all indoor units)
