Names of Parts
INDOOR UNIT
OUTDOOR UNIT

Operation&AdjustingAirowDirection
Refer to the Operating Instructions attached to the Remote Controller.
* The  ap display on the remote controller differs from the actual  ap angle.
A
Model No.
CZ-RTC4
For all indoor
units
Read the Operating Instructions included with the Remote Controller.
Wireless Remote
Controller
Timer Remote
Controller
Wired Remote
Controller
High-spec Wired
Remote Controller
Optional
mini VRF (Type LZ2)
mini VRF (Type LE1, LE2)
2WAY VRF (Type ME2)
3WAY VRF (Type MF3)
NOTE
Refer to the Operating Instructions attached to the
outdoor unit.
4, 5, 6 HP
Air intake (rear, left side)
Air outlet
Anchor hole
Drain port (bottom)
8,10 HP
Model No. CZ-RWS3
The receiver :
Model No. CZ-RWRC3
(For all indoor units)
(Infrared Remote Controller)
Model No.
CZ-RTC5B
For all indoor
units
Model No.
CZ-RTC6*
For all indoor
units
Front panel
Emergency button Emergency button
IndicatorIndicator
Front panel
Air  lters
Air  lters
Type 15, 22, 28, 36 Type 45, 56, 73, 106
Vertical air ow direction louver
• Do not adjust by hand
Horizontal air ow direction
louver
• Manually-operated
adjustable louvers
Horizontal air ow direction louver
• Manually-operated adjustable
louvers
Vertical air ow direction louver
• Do not adjust by hand
Receiver
Receiver
