V Open or close the disc tray
W Knob for DJ and multi control
X Disc tray
Y Microphone jack
Z USB A
USB port ( )
USB status indicator
Play MP3 tracks.
a USB B
USB port ( )
USB status indicator
Play MP3 tracks.
Record sound or music tracks.
b Display panel
c Remote control sensor
Distance: Within approximately 7 m
Angle: Approximately 20° up and down,
30° left and right
d Select the DJ function direct buttons
Press [JUKEBOX] or [DJ] to switch on the DJ function.
Press [DJ1] to [DJ6] on the main unit to select the
desired function.
To cancel, press the selected [DJ1] to [DJ6] again.
SOUND
KARAOKE
MIC VOL
VOL
SELECT
MIC 1 MIC 2
SOUND
K
M
VOL
SELECT
SOUND
KARAOKE
MIC VOL
VOL
SELECT
MIC 1 MIC 2
SOUND
K
M
VOL
SELECT
