Panasonic SC-TMAX50 User Manual

Confidential
Until:
24 Jun 2019
10
TQBJ2189
█ Note on disc
• This system can play CD-R/RW with CD-DA or MP3
format content.
• Before playback, finalize the disc on the device it was
recorded on.
• Some CD-R/RW cannot be played because of the
condition of the recording.
█ Note on USB device
• This system does not guarantee connection with all
USB devices.
• This system supports USB 2.0 full speed.
• This system can support USB devices of up to 32 GB.
• Only FAT 12/16/32 file system is supported.
█ Note on MP3 file
• Files are defined as tracks and folders are defined as
albums.
• Tracks must have the extension
“.mp3” or “.MP3”.
• Tracks will not necessarily be played in the order you
recorded them.
• Some files can fail to work because of the sector size.
MP3 file on disc
• This system can access up to:
– 255 albums (including root folder)
–999 tracks
– 20 sessions
• Disc must conform to ISO9660 level 1 or 2 (except for
extended formats).
MP3 file on USB device
• This system can access up to:
– 800 albums (including root folder)
– 8000 tracks
– 999 tracks in one album
Radio
Preparation
Press [SELECT <, >] repeatedly to select “FM”.
Manual tuning
1 Press [PLAY MENU] repeatedly to select
“TUNE MODE”.
Or press [8] on the unit to select “MANUAL”. Continue
with step 3.
2 Press [R, T] to select “MANUAL” and then press
[OK].
3 Press [2/3] or [5/6] to tune in to the
station.
To tune automatically, press and hold the button until
the frequency starts changing quickly.
Memory presetting
You can preset up to 30 FM stations.
█ Automatic presetting
1 Press [PLAY MENU] to select “A.PRESET”.
2 Press [R, T] to select “LOWEST” or “CURRENT”
and then press [OK].
The tuner presets all the stations it can receive into the
channels in ascending order.
To cancel, press [8].
█ Manual presetting
1 Press [PLAY MENU] repeatedly to select
“TUNE MODE”.
Or press [8] on the unit to select “MANUAL”. Continue
with step 3.
2 Press [R, T] to select “MANUAL” and then press
[OK].
3 Press [2/3] or [5/6] to tune in to the
station.
4 Press [OK].
5 Press [R, T] to select a preset number and then
press [OK].
Do steps 3 through 5 again to preset more stations.
The new station replaces any station that occupies the
same preset number.
LOWEST Tuning begins from the lowest
frequency.
CURRENT Tuning begins from the current
frequency.
SC-TMAX40.50PU_TQBJ2189 En.fm Page 10 Wednesday, June 12, 2019 3:29 PM
offset printing

Panasonic SC-TMAX50 Specifications

General

Impedance	3 Ω
RMS rated power	2000 W
Peak Music Power Output (PMPO)	22000 W
Total Harmonic Distortion (THD)	30 %
Tweeter	Yes
Woofer diameter	100 mm
Tweeter diameter	60 mm
Audio output channels	2.1 channels
Subwoofer driver diameter	200 mm
AC adapter input voltage	220 - 240 V
Preset stations quantity	30
Wi-Fi	No
Bluetooth version	5.0
Power source type	AC
USB 2.0 ports quantity	2
Connectivity technology	Wireless
Recommended usage	Universal
Card reader integrated	-
Audio formats supported	MP3
Mobile operating systems supported	Android
Product type	Mono portable speaker
Product color	Black
AC adapter frequency	50 Hz
Power consumption (standby)	0.6 W
Power consumption (typical)	277 W

Weight and Dimensions

Depth	904 mm
Width	305 mm
Height	326 mm
Weight	20000 g
