7
TQBJ2189
T DJ function direct buttons
Press [DJ] to switch on the DJ function.
Press [DJ1] to [DJ6] to select the desired function.
To cancel, press the selected [DJ1] to [DJ6] again.
U Microphone jack
V :USB A
USB port ( )
Play MP3 tracks.
W :USB B
USB port ( )
Play MP3 tracks.
Record sound or music tracks.
X Remote control sensor
Point the remote control at the remote control
sensor, away from obstacles and within the
operation range.
Distance: Within approximately 7 m
Angle: Approximately 20° up and down, 30° left
and right
Y Display panel
Z Disc tray
SELECT
VOL
DJ6
DJ5
DJ4
DJ3
DJ2
DJ1
SOUND
JUKEBOX
KARAOKE
ALBUM/
TRACK
ILLUMINATION
Top panel
SC-TMAX40.50PU_TQBJ2189 En.fm Page 7 Wednesday, June 12, 2019 3:29 PM
offset printing

Panasonic SC-TMAX50 Specifications

General

Impedance	3 Ω
RMS rated power	2000 W
Peak Music Power Output (PMPO)	22000 W
Total Harmonic Distortion (THD)	30 %
Tweeter	Yes
Woofer diameter	100 mm
Tweeter diameter	60 mm
Audio output channels	2.1 channels
Subwoofer driver diameter	200 mm
AC adapter input voltage	220 - 240 V
Preset stations quantity	30
Wi-Fi	No
Bluetooth version	5.0
Power source type	AC
USB 2.0 ports quantity	2
Connectivity technology	Wireless
Recommended usage	Universal
Card reader integrated	-
Audio formats supported	MP3
Mobile operating systems supported	Android
Product type	Mono portable speaker
Product color	Black
AC adapter frequency	50 Hz
Power consumption (standby)	0.6 W
Power consumption (typical)	277 W

Weight and Dimensions

Depth	904 mm
Width	305 mm
Height	326 mm
Weight	20000 g
