Parts Location
A-BOARD (FOIL SIDE)
Q1100 G-4
Q1101 G-4
Q1102 G-4
Q1103 G-4
Q1105 G-4
Q1106 G-4
Q1107 G-5
Q1108 G-4
Q2101 G-5
Q2102 G-5
Q2104 F-5
Q2105 G-5
Q2200 G-2
Q4504 E-2
Q4505 E-2
Q4528 D-2
Q5603 C-3
Q5604 C-3
Q5684 G-5
Q5740 B-4
Q5741 B-4
Q8000 D-2
Q8001 D-2
Q8002 C-2
Q8003 B-2
Q8300 G-4
Q9002 F-5
Q9003 F-5
Q9301 D-6
Q9302 E-6
TRANSISTOR
IC1100 F-4
IC1101 F-3
IC1102 G-5
IC2107 G-2
IC2108 F-6
IC2109 G-5
IC3001 G-3
IC4501 E-2
IC4508 D-2
IC5401 B-5
IC5606 F-5
IC5607 C-4
IC5608 C-4
IC5740 B-4
IC8003 B-3
IC8004 B-3
IC8502 C-2
IC8503 D-3
IC9004 F-6
IC9802 B-6
IC9803 B-6
IC9809 B-6
ICIC
TP001 G-4
TP002 G-4
TP100 H-2
TP101 H-2
TP102 H-2
TP103 H-2
TP104 H-2
TP105 H-2
TP1100 F-3
TP1101 F-3
TP1102 F-3
TP1103 F-3
TP1105 F-3
TP1110 G-5
TP2027 B-3
TP2028 B-4
TP2100 H-6
TP2101 H-6
TP2102 H-5
TP2103 H-5
TP2104 G-5
TP3000 G-2
TP3001 G-2
TP3501 C-6
TP3503 C-6
TP3504 G-3
TP3505 G-3
TP3507 C-6
TP3508 G-3
TP3518 B-5
TP3519 B-6
TP3521 C-6
TP3522 C-6
TP3523 C-6
TP3526 D-6
TP3527 C-6
TP3528 C-6
TP4001 G-6
TP4002 G-6
TP4003 H-6
TP4004 G-6
TP4005 G-6
TP4006 H-6
TEST POINT
Parts Location
A-BOARD (COMPONENT SIDE)
IC4500 E-2
IC4503 F-2
IC4800 B-2
IC5480 E-3
IC8001 G-2
IC8002 G-3
IC8005 H-3
IC8007 H-2
IC8008 F-1
IC8009 G-2
IC8010 G-3
IC9001 E-6
IC9003 C-5
IC9300 F-5
IC9303 D-5
IC9500 G-5
IC9805 H-4
IC9806 D-5
IC9807 G-5
IC9808 H-6
IC9902 F-5
IC9903 F-4
IC
Q2201 C-2
Q4100 H-3
Q4514 B-2
Q4515 C-2
Q4516 C-2
Q4517 C-3
Q4529 F-3
Q4530 F-3
Q4531 F-3
Q5522 C-3
Q5685 F-4
Q5686 H-4
Q5687 G-4
Q5700 G-4
Q9000 D-6
Q9001 D-6
Q9004 D-6
Q9807 H-6
TP1104 B-5
TP3500 H-5
TP3502 H-5
TP3506 H-5
TP3520 H-5
TP9311 G-4
TP9312 G-4
TRANSISTOR
TEST POINT
TP4500 E-3
TP4501 E-2
TP4502 E-2
TP4503 D-2
TP4506 E-2
TP4508 E-2
TP4512 G-2
TP4513 D-1
TP4514 D-1
TP4519 G-2
TP4525 E-2
TP4526 E-2
TP4527 E-2
TP4528 D-2
TP4529 D-2
TP4530 G-5
TP4800 H-2
TP4801 H-2
TP5400 B-5
TP5489 D-3
TP5600 C-3
TP5601 C-3
TP5602 B-3
TP5700 C-3
TP5740 B-3
TP8000 D-3
TP8300 G-3
TP8301 G-3
TP8302 G-4
TP8303 H-4
TP8304 G-4
TP8305 G-4
TP8503 E-4
TP8505 E-4
TP8521 F-4
TP8522 F-4
TP8524 E-4
TP8526 F-4
TP8527 E-4
TP8528 E-4
TP8529 E-4
TP8530 E-4
TP8531 F-4
TP8532 F-4
TP8534 F-4
TP8548 B-1
TP8549 B-1
TP8550 B-2
TP8551 B-2
TP8552 B-2
TP8553 C-1
TP8554 C-1
TP8555 C-1
TP8566 F-4
TP8567 F-4
TP8568 D-2
TP8569 D-3
TP8570 D-3
TP8571 D-3
TP8572 E-4
TP8573 E-4
TP9000 E-5
TP9006 C-5
TP9010 E-6
TP9020 C-3
TP9021 C-3
TP9022 D-4
TP9023 D-3
TP9024 D-4
TP9025 D-3
TP9026 C-3
TP9027 C-3
TP9028 D-4
TP9029 D-3
TP9030 D-4
TP9031 D-3
TP9032 D-3
TP9033 D-3
TP9034 D-4
TP9035 D-3
TP9036 D-4
TP9037 D-4
TP9038 D-4
TP9039 D-4
TP9040 D-3
TP9041 D-4
TP9042 D-4
TP9043 D-4
TP9044 D-3
TP9076 D-4
TP9077 D-4
TP9078 E-4
TP9079 F-5
TP9080 F-6
TP9081 E-6
TP9082 F-5
TP9196 C-5
TP9197 B-4
TP9198 D-5
TP9199 D-5
TP9200 F-5
TP9201 F-6
TP9202 F-6
TP9203 F-6
TP9204 E-6
TP9205 B-4
TP9206 B-4
TP9207 C-4
TP9208 F-6
TP9209 E-6
TP9210 E-5
TP9500 C-5
TP9862 C-5
TPSOS G-3
