Panasonic TC-P55VT60 - Troubleshooting Blink Codes

Slide 47
Troubleshooting 1, 9, 13 Blinks Failure (All VT60 and ZT60 Models)
When the TV shuts down and the power LED blinks 1, 9 or 13 time, replace the A board
Blink
Code
List of boards likely to cause this symptom
No.1 No.2 No.3 No.4
1 A Board
9 Blinks A Board
10 Blinks A Board
13 Blinks A Board
Slide 47
TC-P60ZT60
TC-P65VT60
TC-P60VT60
TC-P55VT60
Applies to
Models
TC-P65ZT60
