English
15
■ Fixing the cables using the cable tie
Attach the cable tie
Insert the cable tie in a hole
Hole
Bundle the cables
Hooks
Set the tip in the hooks
To loosen:
Knob
Keep pushing the knob
To remove from the TV:
Keep pushing both side snaps
Snaps
<Example>
●
Fix cables as necessary.
●
When using the optional accessory, follow the option’s
assembly manual to fix cables.
■ Attaching the terminal cover / pedestal
cover
●
Do not apply load to the terminal cover / pedestal
cover.
●
Be careful not to nip the cables between the TV and
the terminal cover / pedestal cover.
●
When using USB 2 port, USB 3 port, AV terminal,
DIGITAL AUDIO, HDMI3 terminal or HDMI4 terminal,
you cannot attach the terminal cover. Keep the
removed terminal cover for future use.
C
To Next Page
