English
7
Assembling the pedestal
●
Select a method to assemble the pedestal from the
following styles.
●
Do not assemble the pedestal by any method other
than those specified below.
■ <Style 1>
1
2
1
2
Installing the TV
Assembling / Removing the pedestal
Assembly screw (4)
M5 × 12 (mm)
Assembly screw (4)
M4 × 12 (mm)
Bracket
1
Bracket
2
Base
1
Base
2
Preparations
Take out the pedestal and the TV from the packing case
and put the TV onto a work table with the screen panel
down on the clean and soft cloth (blanket, etc.)
●
Use a flat and firm table bigger than the TV.
●
Do not hold the screen panel part.
●
Make sure not to scratch or break the TV.
