Panasonic TOUGHBOOK CF-31UFLAX series - Replacement Parts List; Main Block Unit Components

Replacement Parts List
CF-31UFLAXxM
PART NO. DESCRIPTION Q'TY
E1 DL3UP2098AAA
PCB, MAIN UNIT
RTL 1
E2 DL31U2121AAA
PCB, WWAN-RFSW
RTL 1
E3 DL32U2121AAA
PCB, USB3
RTL 1
E4 DL33U2121AAA
PCB, KBD
RTL 1
E5 DL34U2121AAA
PCB, SW LED
RTL 1
E6 DL36U2121AAA
PCB, EXT ANTENNA D
RTL 1
E7 DFWP0179ZA
FPC(MP)
1
E8 DL3UP2030AAA
FPC, MK2 HDD ETC UNIT
1
E9 DFWP0181ZA
FPC(BATTERY)
1
E10 DL3UP2079BAA
PCB, TS UNIT
RTL 1
E13 CR-2032/K5GN
LITHIUM COIN BATTERY
1
E16 DFJK40T030DB
FFC KBD
1
E17 DFJS1046YB
LAN CABLE
1
E19 K1NA26Z00002
EXPRESS CONNECTOR
1
E20 K1NA68Z00012
PCMCIA CONNECTOR
1
E21 S N5HZC0000060
WIRELESS LAN/BT MODULE
1
E22 DFJS1233YA
LCD CABLE
1
E23 S N3CAYYY00134
HDD, SATA 7MM 500GB
1
E24 N2ABZY000152
KEYBOARD US
NRP 1
E25 N5ZZ00000241
SO-DIMM 4GB(SAMSUNG)
1
E26 DFWV84A0362
TOUCH PANEL KIT
1
E26
-
1
DL4DT0206AAA
TS FILM UNIT
1
Note : Important Safety Notice
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer's specified parts.
Main Block Unit
REF. NO and AREA
E26 1
DL4DT0206AAA
TS
FILM
UNIT
1
E26-1-1 DFHR3P59ZA
PROTECTIVE FILM
NRP 1
E26-3 DFHP7381ZA
TS TAPE
NRP 1
E27 DFUP1948ZA
FPC, SIM SD WWAN 40P
1
E28 DFUP1812YA
FPC, IO 40P
1
E29 DFUP2052ZA
FPC, IO 60P
1
E30 DFUP1958YA
FPC, USB3
1
E31 DL33U2120AAA
SD WOFF-SW PWB
1
E32 DFWV08A0168
LCD UNIT ASS'Y
1
E32-3 DFHG2230ZAT
LCD DMP SHEET SIDE
NRP 2
E32-4 DFHG2228XA
LCD DMP SHEET TOP
NRP 1
E32-5 DFHG2229ZAT
LCD DMP SHEET BOTTOM
NRP 1
E41 DL31U2120AAA
PCB, IOSUB
RTL 1
E42 DL32U2120AAA
PCB, PAD
RTL 1
E44 DFWP0182ZA
FPC(LED)
1
E45 DFJS1320ZA
CABLE (GRAY, LONG)
1
E46 DFJS1339ZA
CABLE (GRAY, SHORT)
1
E47 DFJS1341ZA
CABLE (WHITE, WLAN MAIN)
1
E48 N1ZYYY000093
PCB, ANTENNA WWAN MAIN + WLAN MAIN
1
E49 N1ZYYY000094
PCB, ANTENNA WWAN SUB
1
E50 N1ZYYY000097
PCB, ANTENNA WLAN SUB
1
E58 DFUP1961ZA
FPC, WL-OFF SD
1
E701 DFJS1321ZA
CABLE
1
E702 DFJS1340ZA
CABLE
1
E704 DL37U2121AAA
DUMMY PCB
RTL 1
A1 S DFQW5649ZAT
MANUAL(CF-31MK3 M)
1
A2 S K2CG3DR00004
AC CORD
1
A3 S CF-AA5713AM1
AC ADAPTOR
1
A4 DFHR6642YA-0
TOUCH PEN
1
Accessories
13/33
