Ref. No. Part No. Part Name & Description Remarks
1 EASG15S509A2 SPEAKER
EUR511048 REMOTE CONTROL
J0KG00000088 CORE CLAMPER
2 KDY4UHE05F DEFLECTION YOKE
KRCBC160928B CORE CLAMPER
3 M68LUQ085XL PICTURE TUBE
4 TBL4G3403 SET LEG
5 TBL4G3405 SET LEG
6 TBM4G0938 MODEL NAME PLATE
7 TBM4G3011 PANASONIC BADGE
8 TBX4G89111 POWER BUTTON
TES4G406 COIL SPRING
TJB1726400 75OHM ADAPTOR
TKK4G8584 LED PANEL
9 TKP4G12881-1 DOOR
TKP4G12901 SMOKED PANEL
10 TKP4G12931 REAR AV BRACKET
11 TKU4GA0510-1 BACK COVER
12 TLK4G9041 ROTATION COIL
13 TLK4G9077T DEGAUSSING COIL
TMM4G502 RUBBER WASHER
14 TMM4G503 RUBBER WEDGE
NLA TNP4G171AC G BOARD
NLA TNP4G181AG X BOARD
NLA TNP4G189BG DG BOARD
NLA TNP4G203AA DG2 BOARD
NLA TNP4G217AF L BOARD
NLA TNP4G235AE P BOARD
NLA TNP4G289AC H BOARD
NLA TNP4G290AD A BOARD
TPC4G49106 CARTON
TPD4G1111-1 TOP CUSHION (REAR)
TPD4G2099 CUSHION (BOTTOM)
TPE4G14023 SET COVER
TPE4G14024 TOP COVER
TQB4G3519 FAN BAG ASSY
TSM10032-4 PURITY MAGNET
TSN63115-4 PURITY MAGNET
TSPX4G002 SUB WOOFER BOX
TSX4G161H AC POWER CORD
15 TXFKY02AR02 CABINET ASSY
TXFPD01AS05 CUSHION (TOP)
RESISTORS
R101 ERJ3GEY0R00 M 0OHM,J,1/16W
R106 ERJ3GEYJ100 M 10OHM,J,1/16W
R107 ERG3ANJ153 M 15KOHM,J, 3W
R110 ERJ3GEYJ472 M 4.7KOHM,J,1/16W
R115 ERJ3GEY0R00 M 0OHM,J,1/16W
R120 ERJ3GEYJ683 M 68KOHM,J,1/16W
R121 ERJ3GEYJ683 M 68KOHM,J,1/16W
R351 ERJ3GEYJ271 M 270OHM,J,1/16W
R352 ERJ3EKF1801 M 1.8KOHM,F,1/16W
R353 ERJ3EKF1401 M 1.4KOHM,F,1/16W
R354 ERG3FJ823H M 82KOHM,J, 3W
R355 ERJ3GEY0R00 M 0OHM,J,1/16W
R356 ERJ3GEYJ822 M 8.2KOHM,J,1/16W
R357 ERC12GK561 S 560OHM,K, 1/2W
R360 ERJ3GEYJ221 M 220OHM,J,1/16W
R361 ERJ3EKF1801 M 1.8KOHM,F,1/16W
R362 ERG3FJ823H M 82KOHM,J, 3W
R363 ERJ3EKF1401 M 1.4KOHM,F,1/16W
R364 ERJ3GEY0R00 M 0OHM,J,1/16W
R365 ERJ3GEYJ682 M 6.8KOHM,J,1/16W
R366 ERC12GK561 S 560OHM,K, 1/2W
R370 ERJ3GEYJ271 M 270OHM,J,1/16W
R371 ERJ3EKF1801 M 1.8KOHM,F,1/16W
R526 ERJ3EKF2202 M 22KOHM,F,1/16W
R527 ERJ3GEY0R00 M 0OHM,J,1/16W
R528 ERJ3GEYJ103 M 10KOHM,J,1/16W
R529 ERJ3GEYJ223 M 22KOHM,J,1/16W
R530 ERG3FJ222H M 2.2KOHM,J, 3W
R531 ERDS2TJ222 C 2.2KOHM,J, 1/4W
Ref. No. Part No. Part Name & Description Remarks
R532 ERDS2TJ222 C 2.2KOHM,J, 1/4W
R533 ERDS2TJ153 C 15KOHM,J, 1/4W
R534 ERDS2TJ272 C 2.7KOHM,J, 1/4W
R535 D0AE912JA046 C 9.1KOHM,J, 1/4W
R536 ERDS2TJ274 C 270KOHM,J, 1/4W
R537 ER0S2CKF1002 M 10KOHM,F, 1/4W
R538 ERDS2TJ222 C 2.2KOHM,J, 1/4W
R539 ERDS2TJ104 C 100KOHM,J, 1/4W
R540 ERDS2TJ223 C 22KOHM,J, 1/4W
R541 ERDS2TJ101 C 100OHM,J, 1/4W
R542 ERJ3GEYJ222 M 2.2KOHM,J,1/16W
R543 ERJ3GEYJ103 M 10KOHM,J,1/16W
R544 ERJ3GEYJ102 M 1KOHM,J,1/16W
R545 ERDS2TJ104 C 100KOHM,J, 1/4W
R546 ERDS2TJ271 C 270OHM,J, 1/4W
R547 ERX3FJ1R0H M 1OHM,J, 3W
R549 ERG1FJS561D M 560OHM,J, 1W
R551 ERF2AKR18 W 0.18OHM,K, 2W
R555 ER050CKF2802 M 28KOHM,F, 1/2W
R556 ER0S2CHF2872 M28.7KOHM,F, 1/4W
R557 ER0S2CHF4702 M 47KOHM,F, 1/4W
R558 ER0S2CHF1502 M 15KOHM,F, 1/4W
R559 ER0S2CHF3902 M 39KOHM,F, 1/4W
R565 ERDS2TJ103 C 10KOHM,J, 1/4W
R566 ERDS2TJ334 C 330KOHM,J, 1/4W
R567 ERDS2TJ223 C 22KOHM,J, 1/4W
R568 ERDS2TJ154 C 150KOHM,J, 1/4W
R569 ERJ3GEYJ332 M 3.3KOHM,J,1/16W
R575 ERJ3GEYJ221 M 220OHM,J,1/16W
R576 ERJ3GEYJ391 M 390OHM,J,1/16W
R577 ERJ3GEYJ562 M 5.6KOHM,J,1/16W
R578 ERJ3GEYJ102 M 1KOHM,J,1/16W
R579 ERJ3GEYJ102 M 1KOHM,J,1/16W
R583 ERG3FJ151H M 150OHM,J, 3W
R705 ERF5ZJ471 W 470OHM,J, 5W
R714 ERDS1FJ680 C 68OHM,J, 1/2W
R719 ERF5AK4R7 W 4.7OHM,K, 5W
R801 TAR26NJ2R7Z W 2.7OHM,J, 7W
R808 ERQ14AJ100E F 10OHM,J, 1/4W
R809 ERG2FJ470H M 47OHM,J, 2W
R812 ERDS2TJ104 C 100KOHM,J, 1/4W
R813 ERG2SJS104H M 100KOHM,J, 2W
R817 ERDS1TJ330 C 33OHM,J, 1/2W
R818 ERG2DJ204P M 200KOHM,J, 2W
R819 ERDS2TJ101 C 100OHM,J, 1/4W
R820 ERX12SZJR12E M 0.12OHM,J, 1/2W
R821 ERX12SZJR12E M 0.12OHM,J, 1/2W
R823 ERDS2TJ152 C 1.5KOHM,J, 1/4W
R824 ERDS2TJ153 C 15KOHM,J, 1/4W
R825 ERDS2TJ123 C 12KOHM,J, 1/4W
R826 ERG1SJ223P M 22KOHM,J, 1W
R827 ERX12SJ1R0E M 1OHM,J, 1/2W
R828 ERDS2TJ681 C 680OHM,J, 1/4W
R829 ERDS2TJ682 C 6.8KOHM,J, 1/4W
R832 ERDS2TJ102 C 1KOHM,J, 1/4W
R834 ERDS2TJ103 C 10KOHM,J, 1/4W
R840 ERD75TAJ825 C 8.2MOHM,J, 3/4W
R851 ERQ2CKR33 F 0.33OHM,K, 2W
R853 D0D5R33KA007 W 0.33OHM,K, 5W
R854 D0D5R33KA007 W 0.33OHM,K, 5W
R858 ERJ3GEYJ472 M 4.7KOHM,J,1/16W
R1114 ERJ3GEYJ472 M 4.7KOHM,J,1/16W
R1115 ERJ3GEYJ101 M 100OHM,J,1/16W
R1116 ERJ3GEYJ101 M 100OHM,J,1/16W
R1117 ERJ3GEYJ101 M 100OHM,J,1/16W
R1118 ERJ3GEYJ101 M 100OHM,J,1/16W
R1119 ERJ3GEYJ472 M 4.7KOHM,J,1/16W
R1120 ERJ3GEYJ101 M 100OHM,J,1/16W
R1121 ERJ3GEYJ101 M 100OHM,J,1/16W
R1122 ERJ3GEYJ101 M 100OHM,J,1/16W
R1123 ERJ3GEYJ101 M 100OHM,J,1/16W
R1124 ERJ3GEYJ562 M 5.6KOHM,J,1/16W
10.2. Replacement Part List
