English
16
Terminals
2
3
4
5
6
7 8 9 10
1
1 Model name plate
2 CI slot (p. 19)
3 Headphone jack (p. 18)
4 HDMI1 - 3 (p. 17, 18)
5 USB 1 port
6 Terrestrial / cable terminal
(p. 16)
7 AV (COMPONENT / VIDEO) (p. 18)
8 ETHERNET terminal
(p. 17)
9 DIGITAL AUDIO
10
USB 2 - 3 port
To watch content in 4K format, use HDMI terminal.
(p. 18)
Basic connections
Mains lead
AC 220-240 V
50 / 60 Hz
Mains lead
Aerial
TV
Cable
RF cable
Terrestrial aerial
For DVB-C, DVB-T, Analogue
DVB-via-IP client connection
This TV has DVB-via-IP client function and can connect
to DVB-via-IP server or SAT>IP compatible servers to
receive broadcast streaming.
It is recommended to connect to DVB-via-IP server
with a LAN cable.
Wired connection
TV
Cable
LAN cable (Shielded)
Use Shielded Twist Pair (STP) LAN cable.
DVB-via-IP server
RF cable
Terrestrial aerial
Satellite dish
