Assembling / Removing the pedestal
Assembly screw (4)
M5 × 14
Assembly screw (4)
M4 × 12
Bracket
Bracket
Base
Base
Cover (2)
Preparations
Take out the pedestal and the TV from the packing case
and put the TV onto a work table with the screen panel
down on the clean and soft cloth (blanket, etc.)
Use a flat and firm table bigger than the TV.
Do not hold the screen panel part.
Make sure not to scratch or break the TV.
Assembling the pedestal
40-inch model
Select a method to assemble the pedestal from the
following 2 styles.
50-inch model
58-inch model
65-inch model
Select a method to assemble the pedestal from the
following 4 styles.
Do not assemble the pedestal by any method other
than those specified below.
To Next Page
