8
English
2
3
B
Removing the pedestal from the TV
Be sure to remove the pedestal in the following way
when using the wall-hanging bracket or repacking the
TV.
1 Remove the assembly screws
B
from the TV.
2 Pull out the pedestal from the TV.
3 Remove the assembly screws
A
from the bracket.
Assembling / Removing the pedestal
A
Assembly screw (4)
M5 × 15
B
Assembly screw (4)
M4 × 12
C
Bracket (2)
D
Base
Assembling the pedestal
A
C
D
1
To Next Page
