18
Single Split Outdoor Unit (R32)
Oceania
Model Name
U-25PZ3R5 U-36PZ3R5 U-50PZ3R5 U-60PZ3R5
Power source 230 - 240 V
～
50 Hz
Cooling capacity
kW
2.5 3.6 5.0 6.0
BTU/h
8,500 12,300 17,100 20,500
Heating capacity
kW
3.2 3.6 5.0 6.0
BTU/h
10,900 12,300 17,100 20,500
Sound pressure level
(Cooling / Heating)
dB(A)
48 / 49 48 / 49 48 / 49 48 / 49
Sound power level
(Cooling / Heating)
dB(A)
66 / 67 66 / 67 66 / 67 66 / 67
Unit dimensions
(H×W×D)
mm
619×824×299 619×824×299 619×824×299 695×875×320
Net weight
kg
31 31 35 43
Operation condition temperature range
•Coolingmode:-10°C~43°CDB•Heatingmode:-15°C~24°CDB
Rated conditions
Cooling : Indoor intake air temp. 27°C DB / 19°C WB. Outdoor intake air temp. 35°C DB.
Heating : Indoor intake air temp. 20°C DB. Outdoor intake air temp. 7°C DB / 6°C WB.
Outdoor unit
Specications
WhenconnectingRACMultioutdoorunit,seeSection“Supplement”aswell.
