Basic Connection
12
Connections
Mains lead and aerial
■ Digital TV, Analogue TV
AC 220-240 V
50 / 60 Hz
Mains lead
Aerial
RF cable
■ Mains lead
Insert the mains plug (supplied) firmly into place.
●
When disconnecting the mains lead, be absolutely sure to
disconnect the mains plug at the socket outlet first.
If the aerial is placed in the wrong location, interference might happen.
Note
●
Keep the space between the TV and RF cable to prevent distorted image.
●
Do not put the RF cable close to the mains lead to avoid noise.
●
Do not place the RF cable under the TV.
●
To obtain optimum quality picture and sound, an aerial, the correct cable (75 coaxial), and the correct terminating
plug are required.
●
If a communal aerial system is used, you may require the correct connection cable and plug between the wall aerial
socket and the TV.
●
Your local Television Service Centre or dealer may be able to assist you in obtaining the correct aerial system for your
particular area and the accessories required.
●
Any matters regarding aerial installation, upgrading of existing systems or accessories required, and the costs
incurred, are the responsibility of you, the Customer.
●
To obtain optimum quality picture, select either an Aerial or a cable TV network.
