5
Accessories
Remote Control
(p. 10)
●
N2QAYB000830
Batteries (2)
●
R6
(p. 10)
Pedestal
(see below)
Mains lead
(p. 6)
Operating Instructions
Production Registration Leaflet
●
Accessories may not be placed all together. Take care not to throw them away unintentionally.
●
For the information of optional accessories, refer to [eHELP] (Support > Optional accessories).
Assembling / Removing the pedestal
Assembly screw (4)
M5 × 15
Bracket
Assembly screw (4)
M4 × 12
Base
■ Assembling the pedestal
1
A
C
D
B
2
3
Removing the pedestal from the TV
Be sure to remove the pedestal in the following way when using the wall-hanging bracket or repacking the TV.
1 Remove the assembly screws
from the TV.
2 Pull out the pedestal from the TV.
3 Remove the assembly screws from the bracket.
To Next Page
