Panasonic Viera TX-L32XM6E - Specifications

34
Specifications
Model No. TX-L32XM6E
Dimensions (W × H × D)
741 mm × 513 mm × 207 mm (With Pedestal)
741 mm × 448 mm × 55 mm (TV only)
Mass
8.0 kg Net (With Pedestal)
7.0 kg Net (TV only)
Power source AC 220-240 V, 50 / 60 Hz
Panel LED LCD panel
Sound
Speaker (90 mm × 25 mm) × 2, 8 :
Audio output 10 W (5 W + 5 W)
Headphones M3 (3.5 mm) stereo mini Jack × 1
Operating conditions
Temperature: 0 °C - 35 °C
Humidity: 20 % - 80 % RH (non-condensing)
Connection terminals
AV1 input / output SCART (Audio/Video in, Audio/Video out, RGB in)
AV2 input
(COMPONENT /
VIDEO)
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 :)
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
Y 1.0 V[p-p] (including synchronisation)
P
B, PR ±0.35 V[p-p]
HDMI 1 / 2 input
TYPE A Connectors
HDMI1: Content Type
HDMI2: Content Type, Audio Return Channel

This TV supports “HDAVI Control 5” function.
Card slot Common Interface slot (complies with CI Plus) × 1
USB USB2.0 DC 5 V, Max. 500 mA
DIGITAL AUDIO
output
PCM / Dolby Digital / DTS, Fibre optic
Receiving systems /
Band name
Check the latest information
on the available services at
the following website.
(English only)
http://panasonic.net/viera/
support
DVB-C Digital cable services (MPEG2 and MPEG4-AVC(H.264))
DVB-T Digital terrestrial services (MPEG2 and MPEG4-AVC(H.264))
PAL B, G, H, I,
SECAM B, G,
SECAM L, L’
VHF E2 - E12
VHF A - H (ITALY)
CATV (S01 - S05)
CATV S11 - S20 (U1 - U10)
VHF H1 - H2 (ITALY)
UHF E21 - E69
CATV S1 - S10 (M1 - M10)
CATV S21 - S41 (Hyperband)
PAL D, K,
SECAM D, K
VHF R1 - R2
VHF R6 - R12
VHF R3 - R5
UHF E21 - E69
PAL 525/60 Playback of NTSC tape from some PAL Video recorders (VCR)
M.NTSC Playback from M.NTSC Video recorders (VCR)
NTSC
(AV input only)
Playback from NTSC Video recorders (VCR)
Aerial input VHF / UHF
