V
L
R
To record / playback videocassettes / DVDs
(VCR / DVD recorder)
To watch DVDs (DVD player)
To watch camcorder images (Video camera)
To watch cable broadcasts (Set top box)
To play games (Game equipment)
To use amplifier with speaker system
To use Network services for freesat
Q-Link
VIERA Link
(with HDMI) (with HDMI)
Direct TV Recording
: Recommended Connection
These diagrams show our recommendations for connection of your TV to various pieces of equipment.
For other connections, consult the instructions for each piece of equipment, the table below, and the
specifications (p. 79).
Internet
Network
Hub or Router
Shielded Twist Pair (STP)
straight LAN cable
or
Optical digital
audio cable
Fully wired HDMI
compliant cable
To watch
DVDs
(Viewing)
RCA
cable
(Listening)
Fully wired SCART cable
DVD player
To listen with
speakers
Amplifier with
speaker system
To enjoy the sound from
the external equipment in
multi-channel sound
(e.g. Dolby Digital 5.1ch),
connect the equipment to
the amplifier.
For the connections,
read the manuals of the
equipment and amplifier.
Installing the Ferrite core
Pull back the tabs.
(in two places)
Open
Press the cable
through and
close
Ferrite core
(supplied)
Less
than
10 cm
Less than
10 cm
To Next Page
