Aquarea air/water heat pump – Installation manual for monobloc and split systems C, D and E series 05 / 2014
3
Device overview
Device overview
Accessories
Split systems
3.3.2 Split systems
No. Component Quantity Comments Included
1 Mounting plate 1 1 For hydro module ×
2 Drain bend 1 ×
3 Cable ties 3 ×
4 Cable bush 2 ×
5 Screw 3 ×
6 Mounting plate 2 1 For hydro module ×
7 PS moulded part 2 ×
8 Cable tie, long 4 ×
9 Seal 1 ×
10
Add-on circuit board for solar thermal
connection CZ-NS1P
1
Add-on circuit board
for solar thermal connection
11
Hot-water tank
WH-TD20E3E5-UK 200 litres,
WH-TD30E3E5-UK 300 litres
1 Stainless steel tank
12
Hot-water tank
HR 200 200 litres
HR 300 300 litres
1 Enamelled
13
Hot-water tank
HRS 300 300 litres
HRS 500 500 litres
1 Enamelled
14
Temperature sensor installation set CZ-TK1
for third party tanks
1
Sensor with cable and immersion
sleeve for installation in third party
tanks
15
Additional casing heater unit
CZ-NE1P for series:
Aquarea T-CAP
Aquarea HT
Mini monobloc unit
from the Aquarea LT series
1
Heating band attached on the floor
plate inside the unit's casing to
prevent the water incurred during
defrosting from freezing
