6
Note:
• Heating capacities are based on outdoor air temperature of 7°C Dry Bulb (44.6°F Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb) with
controlled indoor water inlet temperature of 30°C and water outlet temperature of 35°C.
• Specification are subjected to change without prior notice for further improvement.
Power Cord Number of core -
Length m (ft) -
Thermostat Electronic Control
Protection Device Electronic Control
Item Unit Indoor Unit
Performance Test Condition EUROVENT
Operation Range Outdoor Ambient °C -20 ~ 35
Water Outlet °C 25 ~ 55
Noise Level dB (A) 30
Power Level dB 43
Dimension Height mm (inch) 644 (25-11/32)
Width mm (inch) 504 (19-27/32)
Depth mm (inch) 295 (11-5/8)
Net Weight kg (lbs) 25 (55)
Refrigerant Pipe Diameter Liquid mm (inch) 6.35 (1/4)
Gas mm (inch) 15.88 (5/8)
Water Pipe Diameter Inlet mm (inch) 19.05 (3/4)
Outlet mm (inch) 19.05 (3/4)
Water Drain Hose Inner Diameter mm (inch) 15.00 (19/32)
Pump Motor Type Capacitor Run Induction Motor (2.5 μF)
No. of Speed 3
Input Power W 100
Hot Water Coil Type Brazed Plate
No. of Plates 48
Size (W x H x L) mm 93 x 81 x 325
Water Flow Rate
l/min (ft
3
/min)
20.1 (0.71)
Water Filter Material Brass (Woven Wire Cloth)
Inner Diameter mm 22
Pressure Relief Valve Water Circuit kPa Open: 190, Close: 183 and below
Flow Switch Magnetic Lead Switch
Protection Device A Residual Current Circuit Breaker (40)
Item Unit
