P&H Electronics Model LA-400B Linear Amplifier
Manual Update by NA5RC Page 4 of 6
MODEL LA-400B PARTS LIST
ITEM
QTY
DESCRIPTION
C1, C2, C3, C4, C10, C11, C13,
C15, C16, C17, C18, C19, C20
13
0.005 mFd, 500 V
C5
1
0.004 mFd, 5000 V
C6
1
150 mmFd, Variable
C7
1
400 mmFd, Variable
C8
1
680 mmFd, Silver Mica
C9
1
330 mmFd, Silver Mica
C12, C21
2
0.005 mFd, 5000 V
C14
1
? mmFd, 1000 V
R1
1
1000 Ω, 2 W
R2
1
12 KΩ, 2 W
R3
1
1.2 KΩ, 2 W
R4, R6
2
25 KΩ Potentiometer
R5
1
0.12 Ω Meter Shunt
RFC1
1
National R-175A
RFC2, RFC3
2
2.5 mH
CR1, CR2
2
1N34A
L1, L2, L3, L4
4
Parasitic Suppressors
L5
1
28 Mc Coil
L6
1
Roller Type Variable Inductor
L7
1
8 H, 300 mA Filter Choke
T1
1
Plate Transformer, 1200-1200 V, 300 mA
T2
1
Filament Transformer, 2.5 V, 5 A
T3
1
Filament Transformer, 12.6 V, 2 A
S1, S2
2
SPST Toggle Switch
S3
1
1 Pole 3 Position Switch
S4
1
2 Pole 3 Position Switch
M
1
0-5 mA
