USER COMPONENTS & SPECIFICATIONS
- 2 -
A. Complete frame assembly with
winch and standard telescoping sections
B. Cradle assembly - less detachable cross arms
D. Complete tripod base assembly
C. Cradle cross arms (1 pair)
DESIGNED FOR OPERATION ON HARD, LEVEL SURFACE AT ROOM TEMPERATURE
IN A DRY ENVIRONMENT AvOID MOISTURE AND WATER
SEE PAGES 1, 3 & 9 FOR IMPORTANT OPERATIONAL WARNINGS
NET WEIGHT
LOADING HEIGHT
MAxIMUM HEIGHT
11’ (335 cm)
15’ (457 cm) w/ optional extension
LOAD RATING
150 lbs. (68 kg) DO NOT EXCEED.
SHEET QUANTITY CAPACITY
Single
34” (86 cm)
Approximately 100 lbs. (45 kg)
