Appendix
© Copyright 2008 Panoramic Corporation
PC-1000 Space Requirements
F
Physical Dimensions
35" W x 42" D x 91" H
Minimum Working Space
48" W x 48" D x 91" H
The PC-1000 weighs approximately 485 pounds
and is freestanding, requiring no extra support in
the wall or fl oor.
The factory confi guration is shipped with
the control panel mounted on the patient's
left side, unless specifi ed by the customer
prior to shipping. The control panel can be
easily relocated to the right side at the time of
installation.
Note: The FDA requires that the technique
factors (kVp meter) be viewable during the
exposure.
91" Maximum
58" Minimum
42"
32"
35"
23"
