8
Remove the protective cap from the Dolly. Protective cap in parking position of the
Range Extender.
5
6
Remove safty protection cap (8mm Allen
Key).
Attach the Range Extender to the Dolly.
7
8
Insert the marked pin into the hole, but not
completely.
Attach Ball locking pin with rope to the dolly‘s
lifting drive.
9
10
Installation
New Classic Plus & X-Type
