PAPILLON 61250 - Rules of Operation; Sector Spraying Nozzle; Conical Spraying Nozzle; Nozzle with Four Adjustable Holes

№
P
arts
n
a
m
e
№
P
arts
n
a
m
e
1
Spra
y
i
n
g
n
o
z
z
le
7 Charger socket
2
Spray
t
u
b
e
8 Voltmeter - Battery status indicator (L - H - N)
3
T
a
n
k
c
o
v
er
9 Electric switch (max power)
4
T
a
n
k
10 Carrying handle
5
Hose
11 Lever lock button
6
Ha
n
d
le
12 Potentiometer - Pressure regulator
3.
RULES OF OPERATION
Sector spraying nozzle:
Suitable for low-growth crops, as well as for spraying with herbicides. Spraying should be in the
direction of the wind, and you need to move in parallel to the selected row.
Conical spraying nozzle:
Suitable for pest extermination. Spraying should be in the direction of the wind, and it is necessary to
move across the selected series.
Nozzle with four adjustable holes:
Suitable for spraying tall crops and fruit trees.
Functioning
Make sure the device's battery is sufficiently charged before use. Pour the pre-prepared liquid into the
tank and close the tank tightly with a lid. Check to see if there is a leak through the bottom of the tank.
Choose from three spray nozzles and place the sprayer on the tube. Turn on the power pump and open
the faucet on the spray tube to start spraying. Both intermittent and continuous spraying is allowed with
lock button (11).
2
8
11
6
5
12
9
7
4
3
10
1
