Watering will begin at 7:00
Duration of watering time span (RUN TIME) will be executed as :
Waters 3 min, stop for 10min
Waters 3 min, stop for 10min
Waters 3 min, stop for 10min
Waters 1 min and stops
<Total spend 3+10+3+10+3+10+1 = 40min>
The next START TIME will be renewed as 7:00 (7:00 + 24hrs) on the following day. So, CYCLE
TIME : 1 DAY means watering one time a day.
So, build-in programmed CYCLE TIME is 1 hour which calculated by programmer automatically.
However, if CYCLE TIME set as 1 HR, which means that the START is sequentially shown 7:00,
8:00,
9:00, 10:00……….. Which, also means watering 1 time per hour and repeats.
Basing on such rule, watering more than 1 time a day is shown as following table :
Number of watering times CYCLE TIME to be set
1 1 DAY
2 12 HR
3 8 HR
4 6 HR
6 4 HR
8 3 HR
12 2 HR
24 1 HR
EXPLANATIONS OF TITLES DISPALYED ON SCREEN :
TIME : Current hours and minutes (indicated on top right corner)
START TIME : Upcoming time to start watering
RUN TIME : Duration of watering minutes (1~199 minutes)
MIST CYCLE :
Watering percentage (10%, 20%, 30%, 40%, 50%, 60%, 70%, 80%, 90%, 100%)
50% or 100% for selecting if RUN TIME value below 10min
CYCLE TIME : The total hours to run out value of RUN TIME in virtue of MIST CYCLE.
Prog. ON : Executing set program
Prog. OFF : Reserving set program and no execution
INSTALL THE BATTERY :
Powered by 1PC 9V square battery <Recommend >
*Remove the control panel *Remove OLD battery
*Press-fit the new battery in the housing *Close the control panel
Replace old battery within 5 minutes to avoid losing the setting program.
FEATURES :
*MIN. operating water pressure : 0.5 bars
*MAX. operating water pressure : 8 bars
