Paradigm SOUNDPLAY - Dimensional Drawings

32
46.1” (117cm)
FRONT VIEW
8.9” (22.7cm)
9.2 ”
(23.4cm)
18.7” (47.5cm)
3.8”
(9.6cm)
AUDIO &
VIDEO
CONNECTIONS
POWER
8.9” (22.7cm)
9.2”
(23.4cm)
18.7” (47.5cm)
3.8”
(9.6cm)
32” (81.3cm )
18.3” (46.4cm)
12” (30.5cm )
BACK VIEW
3.9 ”(9.9cm)
0.4”
(1.1cm)
5”
(12.7cm )
DIMENSIONAL DRAWINGS
WALL MOUNT CONFIGURATION
46.1 ”(117cm)5” (12.7cm )
3.5 ”
(8.9cm)
8.9” (22.7cm)
9.2”
(23.4cm)
18.7” (47.5cm)
3.8”
(9.6cm)
FRONT VIEW
8.9” (22.7cm)
9.2”
(23.4cm)
18.7” (47.5cm)
3.8”
(9.6cm)
BACK VIEW
AUDIO &
VIDEO
CONNECTIONS
POWER
DIMENSIONAL DRAWINGS
TABLE MOUNT CONFIGURATION
