LT5048 (I
ss 9: 11/12)
7
PARAGON 200
0 Plus
Users Instructions
SECTION THREE
Fuel Bed Cleaning and Layout Cont.
Lay second row of loose coals 3 off "B"
and 2 off “A” shapes as shown.
Lay third row of loose coals 2 off "B" shape
and 1 off “A“ shape as shown.
