Sicherheitshinweise • Safety instrucons
Transport and storage
The packaging of the awning must be protec-
ted against wet and damp. Soaked packaging
can come loose and cause accidents.
Transport the awning to the place of instal-
laon in the correct direcon for ng to
prevent turning it in small spaces.
If the awning has to be lied to an elevated
area with the help of ropes, remove it from
the packaging and connect it with hauling
ropes so that it cannot slip out and pull it up
evenly in a horizontal posion.
Proceed in the same manner when uninstal-
ling the awning.
The awning must be protected against
penetrang damp when in storage!
Awnings must be stacked and unstacked so
that they do not prove a hazard to persons
due to pping over or rolling out of posion.
Only create storage facilies and stacks
that can securely take the load. Ensure that
the permissible loads of shelves and other
load-bearing components are not excee-
ded.
You must comply with the general goods
storage principles.
Fixing material
The awning is delivered without any
xing material
The xing material must be selected by the
er to suit the exisng ng base and
reconciled in accordance with the require-
ments of the system and ng base.
You must comply with the specicaons for
the required screw anchor pull-out forces.
According to the Direcve for technical
advice, sale and installaon of folding
arm awnings (BKTex Direcve, Secon 3.8),
dowels that are used to anchor folding arm
awnings must have a general building in-
spectorate approval or a European Technical
Approval (ETA).
When using the xing material ordered as
ng accessories, we do not assume any
liability for professional ng. The er is
solely responsible to ensure that the xing
material is suitable for the respecve ng
base and that the ng is done professio-
nally.
You must adhere to the respecve ng
instrucons of the screw anchor manufactu-
rers!
SERIOUS RISK OF INJURY FROM THE
SPRING-LOADED AWNING COMPO-
NENTS!
The arculated brackets are under great
spring tension!
Test run
Persons must not stand in the moving area
or beneath the awning when it is extended
for the rst me. The xing materials and
consoles must be visually inspected aer the
rst extension.
Installaon
You need the following equipment in order
to guarantee that the awning is properly
ed, and therefore the opmal funconing
of the nished product:
Cordless screwdriver
• Drill
• Spirit level
• Ropes / belts
• Complete tool kit
• Equipment for working at height (scaf-
folding, ladders, cherry picker, etc.) that
meet the current individual occupaonal
health and safety standards.
Apply a maximum force of 20 Nm (= 2 kgm)
when ghtening all screws used for alumini-
um components.
A greater ghtening force may damage
the components and/or the stainless steel
screws.
