Montage • Installaon
Alignment / adjusng the arculated brackets / operaon
Check whether the front prole is level.
To adjust, loosen the locknuts (do not
unscrew them completely). Next, you
can align the marquee by turning the
adjusng screws and seng the lt.
To adjust the sengs, you can li the
arculated brackets slightly. This allows
you to turn the adjusng screws more
easily.
Once you have nished making all
sengs, ghten the locknuts again!
Hook the marquee crank into the crank
sha loop on the gears and make sure
it works eortlessly without any
problems.
The marquee cloth must be wound
onto the sha from above (see
gures); rolling it the other way can
cause damage to the cloth and the
arculated brackets.
When the front prole touches the
sha, try not to connue turning,
as this can cause damage to the cloth,
the front prole and the arculated
brackets.
Make sure the marquee cloth does
not sag. The cloth must always be
tensioned by the arculated brackets.
The arculated brackets must not be
extended completely, as otherwise the
cloth will sag and the brackets could be
damaged when cranking in the cloth.
Sicherungsmuern
Arm
Tragrohr
Einstellschraube
Cloth
Cloth
Front prole
Cloth
Cloth
Locknuts
Adjusting screw
Bracket
Supporting
tube
