Montage • Installaon
Fing the wall console and the marquee
1. Mark the ng height. Make sure that the consoles
are at the exact same height. Use a guide line if
necessary.
2. Make sure that the consoles are located at the moun-
ng points for the marquee brackets! (See specica-
ons / drawing for spacing / posion of wall consoles
on page 7).
3. Drill the holes for the ng anchors (please follow
the manufacturer instrucons!). We recommend
heavy-duty anchors!
4. Vacuum the dust from the bore holes and insert the
anchors into the drilled holes unl the set stop.
5. Remove the locang screws from the consoles.
6. Insert the consoles on the intended threaded rods on
the anchors and ghten the nuts by hand. Align the
consoles using a level. Then, ghten all nuts / screws.
Make sure all fastenings are secure in the wall!
7. Slide the marquee supporng tube into the consoles
and secure the marquee (supporng tube) to the con-
soles using the screws.
8. Make sure that all screws / nuts are ghtened securely.
Fing the marquee takes at least 2 people.
Fixierschraube
Locang screw
