Parasound HCA-2003 - Page 3

-3-
HCA-2003 Front and Rear Panel Drawings
C
urrent O
verload
C
H
1
C
H
2
C
H
3
P
ow
er
O
peration
S
tand by
HCA-2003 High Current Multi Amplifier
LUCASFILMLUCASFILM
Power Switch
Standby/Operation
LEDs
Current Overload LEDs
Rack
Mount Holes
Carry Handle
Figure #2 HCA-2003 Front Panel
Figure #1 HCA-2003 Rear Panel
HCA - 2003
High Current Multi-Amplifier
Parasound Products, Inc
San Francisco, CA U.S.A.
Power Consumption: 1320 W
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Fuse 15 A
Power
AC 120V
60Hz
Input
Channel 1
Main Fuse
AC Cord Connector
Carry Handle
Input
Channel 2
Input
Channel 3
Channel 1 Channel 2 Channel 3
Input Connectors
and Level Controls
Speaker Connectors
THX
Level
THX
Level
THX
Level
LUCASFILM
Manufactured under license
from LucasArts Entertainment
Company. U.S. and Foreign
Patents pending. Lucasfilm
THX Audioand Home THX
Symbols are Trademarks of
LucasArts Entertainment
CompanyLucasfilm is a
Trademark of Lucasfilm Ltd.
CAUTION:
TO PREVENT ELECTRIC SHOCK,
DO NOTREMOVE COVER. NO USER
SERVICEABLEPARTS INSIDE. REFER
SERVICING TOQUALIFIED SERVICE
PERSONNEL.
WARNING:
TO PREVENT FIRE OR SHOCK
HAZARD.DO NOT EXPOSE THIS
UNIT TO RAINOR MOISTURE.
